Microdrones mdLiDAR1000HR aaS | | UAV

Descriere Specificații produs Recenzii

Microdrones presents their first fully integrated LIDAR drone system, in partnership with the industry leader md4-1000. This UAV is specially built for professional and commercial applications and uses. LIDAR is known as the most important technology for capturing geospatial data. This platform can be used in a number of different industries and applications, including mining, construction, environmental changes over time, forestry use, gradient mapping and more.

Professionals responsible for collecting geospatial data should consider mdLiDAR1000 for the following tasks.

- Corridor mapping
- Mining (volume calculation)
- Site monitoring
- Environmental changes (time series)
- Forestry
- Contour mapping
- Leveling / Excavation
- Archeology and cultural heritage
- Construction of highways

The mdLiDAR1000 consistently delivers 6 cm (0.2 ft) accuracy when flying at 40 m (130 ft) at a speed of 3 m / s (6.7 mph).

Technical characteristics:
- UAV platform: md4-1000, robust multirotor platform with three blade prop integration, integrated Cooling Covers, Mag-less Navigation (no need for magnetometer during flight);
- Communication: encrypted digital data link, possibility to command and control the UAV from the tablet or from multiple tablets;
- Fully integrated high resolution LiDAR: Velodyne PUCK VLP-16, 16 lines, +-3 cm, range accuracy, 360° horizontal field of view, 30° Vertical field of view, 300.000 points per second (single return mode), 600.000 points per second (dual return mode), 903nm Class 1 eye safe;
- System accuracy LiDAR Point cloud: 4 cm RMSE;
- Fully integrated high resolution camera sensor for colorizing the point cloud: SONY IMX264;
- Fully integrated IMU for Georeferencing: Applanix APX-15 UAV;
- Fully integrated professional nadir camera: SONY RX1R II (42,4 megapixels, 35 mm lens);
- System accuracy photogrammetry: 1–2 pixels horizontal, 3–4 pixels vertical;
- Weight with payload: 6.5 kg;
- System Operation Temperature: -10° C to 60° C.
The configuration includes:
- 1 x A003992 (mdLiDAR1000HR), UAV multirotor platform (md4-1000) with Velodyne PUCK VLP-16 LiDAR, Applanix APX-15 UAV IMU, wireless communications (mdRC 2.4 GHz with Universal Tablet Mount, mdDDL Digital Data Link (868/900 MHz telemetry) and software (mdWaypoint Navigation, mdLanding Assistant) included;
- 1 x A003845 (Payload only mdMapper1000DG), SONY RX1R II camera with nadir mount and cables;
- 2 x A000238 (md4-1000 Lipo Flight Battery LP62-154) batteries;
- 1 x charger for the batteries;
- 1 x mdLiDAR1000 Training, for 2 operators;
- 1 x Rugged carrying case
Software access: (no permanent licenses included, available on demand based on prepaid tokens)
- mdCockpit software access: for planning, monitoring, adjusting, analyzing, and controlling the flight mission;
- mdInfinity software access: for post processing the data.
- 100 tokens included.
Support included:
- 1 year.
Warranty:
- 12 months.

Category: Multirotor UAV

Weight: 6505 g

Brand: Microdrones GmbH
